Ubuthakathaka be-elekthronikhi ngohlobo lwe-RCCB 125A / 30MA

Uhlobo lwe-Electronic Uhlobo lwe-RCCB 125A / 30mA luyakwazi ukuthola ama-currient asalayo ezisekelweni ngenxa yokuvuza, amasekethe amafushane noma unqamule ngokuzenzakalelayo umkhawulo wokusethiwe, ngaleyo ndlela ukuvikela ukuphepha kwabasebenzi nemishini. Umgomo wayo wokusebenza ususelwa emgomweni wokungeniswa kwe-electromagnetic, lapho kudlula khona okusasele kwe-transformer, kuzokhiqizwa umjikelezo we-magnetic ohambisanayo, okuvuselela umjikelezo we-elekthronikhi ukwenza isenzo sohlelo lokukhishwa.

Imodeli:STFP360-125

Thumela Uphenyo

Incazelo Yomkhiqizo

Imodeli:	Stfopp360-125
Okujwayelekile:	IEC 61008-1
Izici Zamanje Zamanje:	Futhi, futhi
Isigxobo Cha.:	2p, 4p
Kukalwe manje:	16a, 25a, 32a, 40a, 630,100,125a
I-VOLTAGE ekalwe:	230 / 400v AC
Imvamisa ekalwe:	50 / 60hz
Kulinganiselwe okusasele okusebenzayo kwamanje i-IelN:	10A, 30mA, 100MA, 300mA, 500MA
I-rated redial desidual engasebenzi yamanje I ΔNO:	≤0.5iΔ
Kulinganiselwe okunemibandela evamile ye-Short-Circuit CRELTER CASH:	6000a
Kulinganiselwe umjikelezo onemibandela onemibandela I-I1C yamanje:	6000a
Isikhathi Esithuthisiwe:	I-TRIPASHTER≤00.1SEC
I-Residial Tripping Range yamanje:	0.5iΔ ~ Ieln
Ukukhuthazela Nge-Electro-Mechanical:	Imijikelezo engu-4000
I-Torque esheshayo:	I-2.0NM
Isikhungo sokuxhuma:	Isikulungisa isisekelo sensipha
Ukufaka:	35mm din rail ukukhwela

Izici eziyinhloko

Ukuzwela okuphezulu nokuphendula okusheshayo: I-Electromagnetic RCCBS ingathola ama-currient amancane asele, imvamisa ngaphansi kwe-30mA (inani eliqondile ngokuya ngokucaciswa komkhiqizo), bese unqamula ngokushesha umjikelezo ngaphakathi kwama-milliseconds ambalwa, ukuvimbela ngokushesha izingozi zikagesi.

Ukuvikelwa kwe-electromagnetic: Uma kuqhathaniswa ne-RCCS ye-elekthronikhi kuphela, i-Electromagnetic RCCBS ihlanganisa umgomo wokungeniswa kwe-electromagnetic, onokwethenjwa okuphezulu nokuqina futhi kungasebenza ngokujwayelekile ezindaweni ezahlukahlukene ezinokhahlo.

I-MultiFunitionality: Amanye ama-RCCnetic we-electromagnetic nawo ane-overload, umjikelezo omfushane neminye imisebenzi yokuvikela, engavikela ngokuphelele ukuphepha kwemibuthano nemishini.

Kulula ukufaka futhi ulondoloze: I-Electromagnetic RCCBS imvamisa yamukele ukwakheka okujwayelekile, ukwakheka okuhlangene, okulula ukuyifaka, futhi kulula ukwenza ukulungiswa okujwayelekile nokuhlola.

Umgomo Wokusebenza

Umgomo osebenzayo we-Electromagnetic RCCB ususelwa emthethweni weKirchhoff, othi indawo yamanje yokufaka ihlala ilingana nokukhishwa kwamanje (ecaleni elikahle). Lapho kunokuvuza noma iphutha lomhlaba esifundeni, ingxenye yokugeleza kwamanje ngqo emhlabeni ukudlula komthwalo, ukudala okusasele kwamanje. Ngalesi sikhathi, umphathi we-transformer ubona lokhu kumanje okungenakulinganisela futhi kukhiqize i-flux ehambisanayo kazibuthe. Ngemuva kokuthi i-magnetic flux icutshungulwa ngumjikelezo we-elekthronikhi, kuzodala isenzo sokwenza imishini yokuhlunga, ukuze umpheki wesifunda usheshe anqume umjikelezo ngokushesha.

Izimo Zokusebenza

I-Electromagnetic RCCBS isetshenziswa kabanzi ezimweni ezahlukahlukene lapho kutholakala khona ukuvikelwa kagesi, kufaka phakathi kepha kungagcini ku:

Izakhiwo zokuhlala nezentengiselwano: zisetshenziselwa ukuvikela imishini kagesi nokuphepha komuntu siqu, ukuvimba izingozi zikagesi ezishaqekile nemililo kagesi.

Imigqa yokukhiqiza yezimboni: Isetshenziselwa ukuvikela imishini kagesi efana nama-motors, ama-transformers nezinye izinto zikagesi ezivela ekusebenzeni okujwayelekile, ukuvimbela ukulimala kwemishini kanye nesikhathi sokuphumula ngenxa yokugcwala ngokweqile.

Izikhungo zomphakathi: njengezibhedlela, izikole, imitapo yolwazi nezinye izindawo, ezisetshenziselwa ukuqinisekisa ukusebenza okuphephile kwemishini kagesi nokusetshenziswa kukagesi okuphephile kwabasebenzi.

Electronic Magnetic A Type RCCB 125A/30mA
